If the door lock on your 2023, 2024, or 2025 Toyota Prius or Prius Prime does not respond to being locked or unlocked by the remote then the door lock actuator is likely damaged.
We go step by step through the replacement instructions here to get your door lock working properly again.
Welcome to the Bozi Breakdown. TTAC Creator Bozidar “Bozi” Tatarević is a Bosnian-American racing mechanic, writer, and technical consultant born in Sarajevo in 1986. After immigrating to the U.S. in 1995, he learned English in elementary school and eventually turned his passion for cars—fostered by his father Slav—into a full-time career. Laid off from a tech job in 2008, Bozi began wrenching professionally, eventually launching a shop and car export business with his family. His technical message board posts led to a writing career with outlets like TTAC, Motorsport.com, Road & Track and Racecar Engineering.
In 2018, he made his pro mechanic debut at Watkins Glen and now works as a tire carrier and mechanic for Vasser Sullivan Racing in IMSA, with 10 wins and a 2023 GTD Pro title. Bozi also consults via his agency Podium Prime, with clients ranging from race teams to media production companies.
The TTAC Creators Series tells stories and amplifies creators from all corners of the car world, including culture, dealerships, collections, modified builds and more.
A transcript of the video, summarized by AI and edited by a human staffer, is below.
[Image: YouTube]
Become a TTAC insider. Get the latest news, features, TTAC takes, and everything else that gets to the truth about cars first by subscribing to our newsletter.
Transcript:
If you press the remote on your Toyota Prius and nothing happens with the door lock, there’s a good chance the door lock actuator has failed. The actuator sits inside the door and connects to the locking mechanism through a series of rods. Inside the actuator is a small electric motor; when that motor fails, it can no longer move the rods needed to lock or unlock the door.
Here’s how to replace it.
Start in the armrest pocket, which has a sliding cover. Use a plastic trim tool to slide the cover open and expose the bolt inside. Remove this bolt first.
Next, move to the door handle area. Using the plastic trim tool again, pop off the small plastic cover behind the handle. This exposes the second bolt that secures the door panel. Remove it.
Now move to the window switch area. Use the trim tool to carefully pry up the window switch assembly. Disconnect the two electrical connectors and set the switch aside.
With the switch removed, you’ll see the third and final bolt holding the door panel in place. Remove it and set it aside safely.
You can now begin removing the door panel. Start at the lower corner near the speaker grille and work your way along the bottom edge, popping the clips loose as you go. Once the lower portion is free, support the panel while lifting it off so it doesn’t fall to the ground.
After separating the panel, remove the clip at the top that secures the cables for the door lock and door handle. With some room to work, disconnect the cables by sliding them out and rotating them free from their mounting points. This will fully free the door panel so you can access the interior components.
Next, use a T30 Torx bit to remove the bolts securing the door lock actuator to the door. Inside the door there’s also a vertical brace that needs to be removed; take out the two bolts holding it in place with a 10 mm socket.
You’ll also need to loosen the wiring harness mounted across the black plastic inner cover. Unclip the wiring, then remove the two white quarter-turn plastic clips. After that, pop out the remaining plastic push pins so the cover can be loosened.
At this stage it’s usually easier to fully remove the black plastic cover rather than leaving it partially attached. Once it’s loose, feed the door lock and door handle cables through the opening in the cover.
With the cover out of the way, you can work the door lock actuator assembly out of the door. Be careful while removing it because there are linkages connected to the exterior door handle and lock.
Once the actuator is removed, compare it to the replacement part to confirm they match and that the linkages are the same length.
Before installing the new actuator, look inside the door and identify the metal linkages that connect to the door handle and lock. On the back of the actuator you’ll see the two slots where these linkages must attach.
Slowly insert the new actuator into the door. Start by aligning it with the linkage that connects to the exterior lock assembly. Then connect the linkage that runs up to the door handle and align the electrical connector. Once everything is positioned correctly, begin reinstalling the external mounting bolts to hold the actuator in place. After the bolts are started, tighten them fully.
Before reassembling everything, temporarily plug in the actuator to test it. You should be able to move the linkages by hand and then test the locking function using the remote. It’s also a good idea to test the door lock from the outside using the physical key to make sure everything is aligned correctly.
Once you’ve confirmed the actuator works properly, begin reassembly. Start by reinstalling the black plastic inner cover and feeding the actuator linkages back through their original openings. Align the cover with the white clips in the door and snap it into place. Reinstall the quarter-turn clips and secure the wiring harness back into its original clips so nothing gets pinched.
Next, reinstall the metal brace, making sure it’s oriented correctly so it lines up with the bolt that passes through the door panel.
Before reinstalling the door panel, double-check that the actuator cables and wiring are properly routed and not pinched by the cover.
Reinstallation of the door panel is the reverse of removal. Reconnect the door handle and lock cables to the panel first. Then align the panel with the door and reconnect the window switch wiring before pressing the panel clips back into place.
Finally, reinstall the three bolts you removed earlier and snap the trim covers back into place. As a last step, test the door lock again using the remote before closing the door to make sure everything works correctly and the door won’t get stuck due to an installation error.
